Advanced Diagnostic Equipment

We don't guess - we know exactly what's wrong with your ride. Our diagnostic gear reads deeper than most shops even know exists.

Professional Diagnostic Scanner
Factory-Level Scanning
Our Main Arsenal

OEM-Grade Diagnostic Platforms

Look, we've invested seriously in the good stuff here. Not just your basic code reader from the auto parts store - we're talking manufacturer-level diagnostic systems that communicate with every module in your vehicle.

These tools let us dive into everything from your ABS controller to the parking sensors, pulling live data while you're driving. It's pretty wild what modern cars are tracking.

47+
Vehicle Systems
200ms
Data Refresh Rate
Book Diagnostic Scan

Technical Capabilities

Yeah, we geek out over this stuff - here's what our setup can actually do

Deep System Scanning

We're not just reading engine codes - though we do that too. Our scanners access every electronic control unit in your vehicle.

  • Engine management & transmission
  • ABS, stability & traction systems
  • Climate control & body electronics
  • Airbag & safety systems
  • Infotainment & navigation modules
Diagnostic Display
ECU Programming

Module Coding & Flashing

Sometimes fixing your car means rewriting its brain. We handle software updates, module replacements, and feature coding.

  • ECU software updates & reflashing
  • Module replacement programming
  • Feature activation & configuration
  • Key programming & immobilizer reset
  • Adaptation & calibration procedures

Real-Time Data Analysis

This is where things get interesting. We can record what's happening in your car while driving it, catching those intermittent issues that only show up once in a while.

  • Multi-channel data stream recording
  • Road test data logging capability
  • Sensor signal graphing & analysis
  • Bi-directional control testing
  • Component activation & testing
Data Logging

Before & After Reports

Real examples from our shop - names removed for privacy obviously

2018 BMW 340i - Rough Idle
BEFORE

Fault Codes Found:

P0300 - Random Misfire Detected

P0301 - Cylinder 1 Misfire

P0316 - Misfire on Startup (First 1000 Rev)

2A87 - DME: Fuel Quality Poor

Live Data Readings:

Cyl 1 Combustion: -3.2ms (Spec: +/- 1.0ms)

Fuel Trim Bank 1: +18% (High)

Ignition Coil 1 Primary: 4.2A (Spec: 6.0A)

Customer complaint: "Check engine light came on, feels sluggish when cold, rough at idle"

2018 BMW 340i - Post Repair
AFTER

Work Completed:

- Replaced cylinder 1 ignition coil

- Replaced cylinder 1 spark plug (carbon fouled)

- Cleared adaptation values & fault memory

Post-Repair Scan:

No fault codes present

Cyl 1 Combustion: +0.4ms (Within spec)

Fuel Trim Bank 1: +2% (Normal)

Ignition Coil 1 Primary: 6.1A (Spec met)

All cylinders combustion balanced

Test drive confirmed: smooth idle, normal acceleration, no warning lights

2020 Audi Q5 - ABS Warning
BEFORE

Fault Codes Found:

C1234 - ABS Wheel Speed Sensor FR Circuit

C1095 - ABS Pump Motor Circuit Low

U0415 - Invalid Data from ABS Module

Component Testing:

FR Wheel Speed: No signal detected

Sensor Resistance: Open circuit

ABS Pump: Activation test - Intermittent

Customer complaint: "ABS light on, traction control disabled message"

2020 Audi Q5 - Post Repair
AFTER

Work Completed:

- Replaced front right wheel speed sensor

- Cleaned & sealed sensor connector

- Performed ABS bleeding procedure

- Ran system self-test & cleared faults

Post-Repair Verification:

No fault codes stored

All wheel speed sensors: Active signal

ABS self-test: Passed all functions

Road test: ABS intervention normal

Test results: All safety systems operational, no warning lights

Get Started

Book Your Diagnostic Appointment

We keep our schedule pretty tight so we can give each car the attention it deserves. Pick a time that works for you and we'll get your vehicle sorted.

What to Expect:
  • Appointments typically take 1-2 hours
  • You'll get a detailed diagnostic report
  • We'll walk you through what we found
  • Repair quote provided same day

Diagnostic Fee: $165 + tax

Fee waived if you proceed with repairs over $500

Prefer to call? (604) 555-0847

Available Time Slots

Times highlighted in amber are our next openings
Quick Tip: Morning slots usually finish earlier - we're fresh and there's less chance of delays from previous jobs.

Got a weird issue that nobody can figure out?

That's literally our favorite kind of job. Bring it by and let's see what's really going on under the hood.
